| Box Red | Box Brown | Yellow | Box Sliver | |
|---|---|---|---|---|
| Type | Linear | Tactile | Linear | Linear |
| Operating Force | 45±10 gf | 55±10 gf | 50±10 gf | 43±10 gf |
| Pre-travel | 2±0.5 mm | 2±0.5 mm | 2±0.5 mm | 1.2±0.3 mm |
| Travel Distance | 3.8 mm Max | 4 mm Max | 4 mm Max | 3.4 0/-0.4 mm |
| Pre-lubed | Yes | Yes | Yes | Yes |
Specifications:
- MX Structured
- Factory Pre-lubed
- SMD-LED Supported
- Pins: 5-Pin Switch
- Operation Life: Up to 80M Cycles
- Stem Material: Thermoplastic, MX stem
- Upper Housing: Polycarbonate, Transparent Housing
- Housing Base: Polycarbonate, Transparent Base
- Spring: Stainless Steel Spring
Packaging Details:
All switches will be carefully packaged in plastic containers.
