| Red | Brown | Blue | Yellow | |
|---|---|---|---|---|
| Type | Linear | Tactile | Clicky | Linear |
| Operating Force | 45±15 gf | 55±15 gf | 60±15 gf | 50±15 gf |
| Pre-travel | 2±0.6 mm | 2±0.6 mm | 2.3±0.6 mm | 2.3±0.6 mm |
| Travel Distance | 4±0.6 mm | 4±0.6 mm | 4±0.6 mm | 4±0.6 mm |
| Pre-lubed | Yes | Yes | No | Yes |
Specifications:
- MX Structured
- Factory Pre-lubed
- SMD-LED Supported
- Pins: 3-Pin Switch, Plate Mount
- Operation Life: Up to 50M Cycles
- Stem Material: POM, MX stem
- Upper Housing: Proprietary Ink Material, Transparent Housing
- Housing Base: Nylon PA66
- Spring: Stainless Steel Spring
Packaging Details:
All switches will be carefully packaged in plastic containers.
